Senergy Intellution Pvt. Ltd. offers RFID systems, key management, data acquisition, and radiation monitoring solutions.

Overview

Compact
Supports three-factor authentication
Integrated Solution for Access Control
ISO19794-2 compatible
Compatible with ISO14443 (13.56MHz HF), ISO15693, ISO11784/85

Enquire Now

Key Features

Fast Response

Built-in Access controller

Built-in Access controller

Multi-factor authentication

Multi-factor authentication

Features

Quick access
more than 50 mm read range
Audio Indication: Programmable Melodies for different card events.
LED indication: Bi-colour for indicating access status.
Door Lock and Unlock functions for emergencies.

Multi-factor authentication - FP, PIN
Anti-passback (APB).
Secured keyset for RFID card reading.
ISO7816 SAM for customer authentication logic.

Tamper resist numeric keypad for PIN entry
Tamper detection
Protection: The inputs are protected against over-voltage, reverse polarity and over current.

Ethernet LAN
RS485
RS232
Secured communication with Server
Transaction to both Server, Photo popup

Various Sizes and form factors
Colour - black, grey.
Display - B/W or colour.
Display size: 16*2, 2.2”, 2.7”, 3.5”, 7”
With or Without :-Display, FP, Keypad
Configurable relay outputs
Configurable Digital inputs to interface with door / turnstile sensors.

Technical Specification

Card verification time	less than 100ms
employee access conditions	10000
FP templates	20000
Multifactor authentication	Combinations of RF, FP, PIN
Transaction storage	Logs 32000 transaction events
Communication	Ethernet LAN or RS-422/ RS-485 host interface.
Ingress Protection	IP54
Operating Temperature	0-55 Deg. C
Humidity	0-95% RH (Non-condensing)
Power supply	Wide operating range : 7 to 24V dc
